Modeling
The Modeling module covers the full geometry pipeline — from vertex color authoring and modular kit validation through LOD generation, Nanite analysis, UV auditing, physics setup, and scan cleanup.
10 registered tools.
Authoring
Section titled “Authoring”-
Vertex Color Painter Paint vertex colors directly in the level viewport. Configurable brush with channel masking, strength, falloff, and undo support.
VertexColor -
Modular Kit Auditor Audit and optimize modular kit placement. Validate grid snapping, fix issues, convert to instanced meshes, and export kit manifests.
Assembly -
Outline Shell & Cage Builder Generate watertight outer shells and inner cages (offset meshes) for toon outlines, cloth cages, physics padding, and VFX/SDF shells.
Mesh
Audit & Analysis
Section titled “Audit & Analysis”-
Vertex Color Viewer Inspect vertex color channels across static meshes. Detect unused or constant vertex colors. Strip to save memory.
VertexColor -
World-Scale & Traversal Checker Sweep world geometry against character movement params to find steps, gaps, ceilings, and ledges that violate traversal budgets.
Traversal -
Mesh Intelligence Dashboard Project-wide mesh statistics, batching opportunities, and pivot auditing in one 3-tab dashboard.
Stats -
UV & Texel Suite Comprehensive UV analysis: layout checking, texel density, channel management, and UDIM overview.
UV
Optimization
Section titled “Optimization”-
LOD & Nanite Studio Unified LOD and Nanite analysis: complexity metrics, mesh validation, readiness checking, mobile proxy estimates, and LOD generation in one studio.
LOD -
Physics & Collision Studio Manage collision presets and debug physics assets in one studio panel.
Physics
Cleanup
Section titled “Cleanup”-
Scan Cleanup & Remesh Utility Clean up scanned meshes: remesh to watertight, hole fill, self-intersection removal, component isolation, topology analysis.
Modeling
Tool reference
Section titled “Tool reference”| Tool | Category | Type |
|---|---|---|
| Vertex Color Viewer | VertexColor | Single panel |
| Vertex Color Painter | VertexColor | EdMode launcher |
| World-Scale & Traversal Checker | Traversal | Single panel |
| Modular Kit Auditor | Assembly | Single panel |
| Physics & Collision Studio | Physics | 2-tab suite |
| Mesh Intelligence Dashboard | Stats | 3-tab suite |
| UV & Texel Suite | UV | 4-tab suite |
| Scan Cleanup & Remesh Utility | Modeling | 5-tab suite |
| LOD & Nanite Studio | LOD | 5-tab suite |
